XPS Foam Tile Backer Board for Project Supply

Our XPS Foam Tile Backer Board is a premium composite panel built with closed-cell XPS core, double fiberglass mesh and polymer cement coating. As a professional tile backer board supplier, our XPS Foam Tile Backer Board has nearly zero water absorption to stop dampness and mold, plus outstanding thermal insulation matching underfloor heating. Lightweight, fluorine & bromine free and simple to cut for quick installation, this customizable XPS Foam Tile Backer Board suits bathrooms, showers, kitchens and caravan flooring perfectly.
Category:

Introduction:

As a professional and trustworthy tile backer board supplier, our XPS Foam Tile Backer Board is a high-performance composite building panel specially designed for indoor wet areas and thermal insulation projects. Specifically, it is constructed with a premium closed-cell XPS foam core, double-layer fiberglass mesh and durable polymer cement mortar coating, which enables this XPS Foam Tile Backer Board to integrate waterproofing, thermal insulation and structural stability in one single panel.
In terms of waterproof performance, the board features near-zero water absorption and excellent moisture resistance. As a result, it can effectively prevent wall dampness, mold growth, tile hollowing and peeling problems, greatly outperforming traditional cement backer boards. Meanwhile, it comes with low thermal conductivity, providing stable thermal insulation and working perfectly with underfloor heating systems to reduce overall energy consumption.
In addition, this board is lightweight yet rigid and impact-resistant, making it easy to cut, carry and install on site. Therefore, it can significantly save construction time and lower labor costs. Furthermore, it is eco-friendly with zero fluorine and bromine content, fully meeting international environmental standards. Most importantly, with customizable sizes and versatile performance, our XPS Foam Tile Backer Board is highly suitable for bathrooms, shower rooms, kitchens, spas and caravan flooring, serving as the ideal tiling substrate for global residential and commercial decoration projects.

Specification

PROPERTIESSTANDARDSRESULT
DimensionsLengthN/A1200mm/2400mm Or Customized
WidthN/A600mm/1200mm
ThicknessN/A4mm-120mm
Fire PerformanceGB8624-2012B1(B-s1，d0)
Thermal ConductivityGB/T 10295-20080.030-0.036 w/m.k
Compressive Strength (10% Deflection)GB/T 8813-2020300Kpa++
Tensile Strength (Perpendicular)GB/T 29906-2013317 KPa
Water UptakeJG/T 480-2015322 g/m2
Water ImpermeabilityJG/T 480-2015No inner penetration in 3 specimens
Dimensional StabilityGB/T 8811-20080.70%
VOC EmissionGB 50325-20200.029mg/m³
Compressive Creep Rate
(23 °C, 4 kPa, 168 h)		GB/T 15048-19940.40%
Compressive DeformationDG/TJ 08-2365-20211mm
Working temperature rangeN/A﹣50℃ to+80℃

Typical Applications
XPS Foam Tile Backer Insulation Board perfectly integrates waterproofing, thermal insulation and high structural strength. Therefore, it is widely used in residential and commercial wet spaces that require reliable moisture resistance and heat preservation.
1. Excellent waterproof property makes it an ideal watertight substrate for walls and floors in bathrooms, shower rooms and all damp zones.
2. Rigid XPS core delivers great thermal resistance, acting as an efficient insulation layer beneath underfloor heating to cut heat loss.
3. High compressive strength allows it to build sturdy partition walls for wood and steel frame structures.
4. Lightweight, solid, waterproof and simple to install, it perfectly replaces traditional gypsum boards and fiber cement boards.
5. Popular for constructing bathtub surrounds and protective casings for water pipes in indoor renovation.
6. Easy to cut into custom shapes, fast to fabricate into shower benches, wall shelves, washbasin bases and soap niches.
7. Great formability supports custom processing into various decorative structures to match personalized design demands.
